Specifications
| Parameter | Details |
|---|---|
| Model | KCD1-107-N-4 |
| Switch Type | KCD Rocker Switch |
| Function | ON-OFF (Illuminated) |
| Pin | 3 Pin |
| Indicator | LED / Neon Light |
| Contact Type | SPST / SPDT |
| Rated Load | AC125V 10A / AC250V 6A |
| Mounting Type | Panel Mount |
| Electrical Life | ≥10,000 cycles |
| Electrical Life | ≥10,000 cycles |
Key Features
- 3 pin ON-OFF illuminated switch design
- Built-in LED / neon indicator light
- Panel mount installation
- Stable contact performance
- Long electrical life
Applications
- Household appliances
- Power supplies
- Industrial control panels
- Automotive electronics
- DIY electronics
Widely used in electrical systems requiring visual ON/OFF indication, reliable switching, and safe power control.
Why Choose Our Rocker Switch
- Professional KCD1-107-N-4 illuminated rocker switch supplier with stable production capacity
- OEM / ODM customization available for rocker switch with indicator light manufacturer projects
- Reliable 3 pin ON OFF boat switch with LED for appliances and industrial systems
- High-quality panel mount illuminated power switch factory China with strict QC system
- Durable illuminated rocker switch for control panels and electrical equipment
- Fast delivery and global supply support for bulk orders
FAQ
Q1: What is a KCD1-107-N-4 illuminated rocker switch?
It is a 3 pin ON-OFF rocker switch with a built-in indicator light used for power control and status display.
Q2: What is the function of the indicator light?
The indicator light shows whether the circuit is ON or OFF, improving safety and user experience.
Q3: Why does a 3 pin illuminated rocker switch have 3 terminals?
It includes input, output, and indicator light connection for proper lighting function.
Q4: What is the rated voltage and current?
It is typically rated at AC125V 10A or AC250V 6A.
Q5: Does this rocker switch support OEM/ODM customization?
Yes, customization is available for light color, voltage, marking, and packaging.
