Specifications
| Parameter | Details |
|---|---|
| Model | KCD3-103-2 |
| Switch Type | KCD Rocker Switch |
| Function | ON-OFF |
| Pin | 2 Pin |
| Contact Type | SPST |
| Rated Load | AC125V 20A / AC250V 16A |
| Mounting Type | Panel Mount |
| Contact Resistance | ≤50mΩ |
| Insulation Resistance | ≥100MΩ |
| Electrical Life | ≥10,000 cycles |
Core Features of KCD3 2 Pin Rocker Switch
- 2 pin ON-OFF simple control design
- High current rating: 20A 125VAC / 16A 250VAC
- Snap-in panel mount installation
- Compact size with strong load capacity
- Durable mechanical life ≥10,000 cycles
- Flame-retardant housing (PA66)
Technical Specifications
- Model: KCD3-103-2
- Pins: 2 Pin
- Function: ON-OFF
- Rated Voltage: 125V / 250V AC
- Rated Load: 20A @125VAC / 16A @250VAC
- Mounting Type: Panel Mount (Snap-in)
- Panel Size: ~30×22mm
- Electrical Life: ≥10,000 cycles
- Material: PA66 / PC housing
Applications
Industrial control panels and machinery
High-power appliances such as heaters and power tools
Power distribution units and extension sockets
Automotive and marine electrical systems
Summary:
KCD3 2 pin rocker switches are ideal for high-current ON-OFF power control in industrial and electrical applications.
Why Choose Our KCD3 Rocker Switch
- High current capacity up to 20A
- Simple ON-OFF control (easy replacement)
- Full KCD3 model range available
- OEM/ODM customization supported
- Stable quality for industrial applications
- 2 pin 20a rocker switch supplier
- high current on off rocker switch manufacturer
- panel mount rocker switch factory
FAQ
What is a 2 pin rocker switch?
A 2 pin rocker switch is a simple ON-OFF switch used to control a single electrical circuit.
What is the difference between 2 pin and 3 pin rocker switch?
2 pin switches only control ON-OFF, while 3 pin switches can include additional functions like ON-OFF-ON or LED indicators.
Is KCD3-103-2 suitable for high current applications?
Yes, it supports up to 20A current, making it suitable for heavy-duty electrical devices.
