Specifications
| Parameter | Details |
|---|---|
| Model | KCD1-105-N-5 |
| Switch Type | KCD Rocker Switch |
| Function | ON-OFF |
| Pin | 3 Pin |
| Contact Type | SPST |
| Rated Load | AC125V 10A / AC250V 6A |
| Mounting Type | Panel Mount |
| Contact Resistance | ≤50mΩ |
| Insulation Resistance | ≥100MΩ |
| Electrical Life | ≥10,000 cycles |
Key Features
- 3 pin ON-OFF switching design
- SPST / extended wiring structure
- Optional LED indicator version
- Panel mount snap-in installation
- Stable electrical performance with long lifespan
Applications
- Household appliances
- Power supplies
- Industrial control panels
- Automotive electronics
- DIY electronics
Widely used in electrical systems requiring reliable ON-OFF switching, indicator functionality, and stable panel-mounted power control.
Why Choose Our Rocker Switch
- Professional KCD1-105-N-5 rocker switch supplier with stable production capacity
- OEM / ODM customization available for 3 pin rocker switch manufacturer projects with LED options
- Reliable ON OFF boat switch for appliances, automotive, and industrial control systems
- High-quality panel mount rocker switch factory China with strict quality control standards
- Durable 3 pin rocker switch for power control systems with indicator function support
- Fast delivery and global supply support for bulk orders
FAQ
Q1: What is a KCD1-105-N-5 rocker switch?
It is a 3 pin ON-OFF rocker switch used for electrical circuit control, often with optional LED indication.
Q2: What is the difference between 2 pin and 3 pin rocker switch?
2 pin switches are used for simple ON-OFF control, while 3 pin switches allow additional wiring or indicator functions.
Q3: Does this switch support LED indicator?
Yes, some versions of KCD1-105-N series support LED indicator functionality.
Q4: What is the rated load?
It is typically rated at AC125V 10A / AC250V 6A.
Q5: Does this rocker switch support OEM/ODM customization?
Yes, OEM/ODM customization is available for color, LED, marking, and specifications.
