Specifications
| Parameter | Details |
|---|---|
| Model | KCD1-105-2 |
| Switch Type | KCD Rocker Switch |
| Function | ON-OFF-ON |
| Pin | 3 Pin |
| Contact Type | SPDT |
| Rated Load | AC125V 10A / AC250V 6A |
| Mounting Type | Panel Mount |
| Contact Resistance | ≤50mΩ |
| Insulation Resistance | ≥100MΩ |
| Electrical Life | ≥10,000 cycles |
Key Features
- 3 pin ON-OFF-ON switching function
- SPDT multi-position control
- Panel mount snap-in installation
- Stable contact performance
- Long service life
Applications
- Household appliances
- Power supplies
- Industrial control panels
- Automotive electronics
- DIY electronics
Widely used in electrical systems requiring flexible ON-OFF-ON switching, dual circuit control, and reliable panel-mounted operation.
Why Choose Our Rocker Switch
- Professional KCD1-105-2 rocker switch supplier with stable production capacity
- OEM / ODM customization available for 3 pin rocker switch manufacturer projects
- Reliable ON-OFF-ON boat switch for appliances, automotive, and industrial control systems
- High-quality panel mount rocker switch factory China with strict QC standards
- Durable SPDT rocker switch for dual circuit switching and flexible control applications
- Competitive pricing with fast global delivery support
FAQ
Q1: What is a KCD1-105-2 rocker switch?
It is a 3 pin ON-OFF-ON rocker switch used for flexible electrical circuit control with dual switching positions.
Q2: What does ON-OFF-ON mean?
It means the switch has two ON positions and one OFF position, allowing switching between two circuits.
Q3: What is the difference between 2 pin and 3 pin rocker switch?
2 pin is for simple ON-OFF control, while 3 pin allows ON-OFF-ON or dual circuit control.
Q4: What is the rated load?
It is typically rated at AC125V 10A / AC250V 6A.
Q5: Does this rocker switch support OEM/ODM customization?
Yes, customization is available for color, marking, LED indicator, and specifications.
