Specifications
| Parameter | Details |
|---|---|
| Model | KCD1-105-14 |
| Switch Type | KCD Rocker Switch |
| Function | ON-OFF-ON |
| Pin | 6 Pin |
| Contact Type | DPDT |
| Rated Load | AC125V 10A / AC250V 6A |
| Mounting Type | Panel Mount |
| Contact Resistance | ≤50mΩ |
| Insulation Resistance | ≥100MΩ |
| Electrical Life | ≥10,000 cycles |
Key Features
- 6 pin ON-OFF-ON switching design
- DPDT dual circuit control structure
- Supports polarity reversing and dual load switching
- Panel mount snap-in installation
- High durability and stable contact performance
Applications
- Industrial control systems
- Automotive electrical systems
- Motor forward/reverse control
- Power distribution systems
- DIY electronics
Widely used in electrical systems requiring dual circuit switching, polarity reversing, and multi-mode control for motors, actuators, and automation equipment.
👉 6 Pin rocker switch commonly supports ON-OFF-ON dual circuit control and polarity reversing
Why Choose Our Rocker Switch
- Professional KCD1-105-14 rocker switch supplier with stable production capacity
- OEM / ODM customization available for 6 pin dual circuit rocker switch manufacturer projects
- Reliable ON-OFF-ON DPDT rocker switch for motor control and polarity reversing systems
- High-quality industrial rocker switch factory China with strict quality control standards
- Durable 6 pin rocker switch for automotive, industrial, and power control applications
- Fast delivery and global OEM supply support
FAQ
Q1: What is a KCD1-105-14 rocker switch?
It is a 6 pin ON-OFF-ON rocker switch designed for dual circuit control and advanced switching applications.
Q2: What does a 6 pin rocker switch do?
It allows switching between two circuits or reversing polarity in electrical systems.
Q3: What is DPDT in a rocker switch?
DPDT (Double Pole Double Throw) enables simultaneous control of two circuits or direction switching.
Q4: Where is this switch commonly used?
It is widely used in automotive systems, motor control, industrial automation, and power distribution systems.
Q5: Does this rocker switch support OEM/ODM customization?
Yes, customization is available for LED, wiring configuration, symbols, and specifications.
