Specifications
| Parameter | Details |
|---|---|
| Model | KCD1-105-11 |
| Switch Type | KCD Rocker Switch |
| Function | ON-OFF-ON |
| Pin | 3 Pin |
| Contact Type | SPDT |
| Rated Load | AC125V 10A / AC250V 6A |
| Mounting Type | Panel Mount |
| Contact Resistance | ≤50mΩ |
| Insulation Resistance | ≥100MΩ |
| Electrical Life | ≥10,000 cycles |
Key Features
- 3 position ON-OFF-ON switching design
- 3 pin SPDT structure
- Panel mount snap-in installation
- Supports dual circuit or mode switching
- Stable contact performance and long lifespan
Applications
- Household appliances
- Industrial control panels
- Power supplies
- Automation equipment
- DIY electronics
Widely used in electrical systems requiring multi-mode switching, circuit selection, and reliable ON-OFF-ON control functionality.
Why Choose Our Rocker Switch
- Professional KCD1-105-11 rocker switch supplier with stable production capacity
- OEM / ODM customization available for 3 position rocker switch manufacturer projects
- Reliable ON-OFF-ON boat switch for appliances, automation equipment, and control panels
- High-quality panel mount rocker switch factory China with strict quality control
- Durable SPDT rocker switch for multi-mode switching and circuit selection applications
- Fast delivery and global supply support for bulk orders
FAQ
Q1: What is a KCD1-105-11 rocker switch?
It is a 3 pin ON-OFF-ON rocker switch used for switching between two circuits or operating modes.
Q2: What does three position rocker switch mean?
It means the switch has three positions, typically ON-OFF-ON, allowing multiple circuit control options.
Q3: What is SPDT in a rocker switch?
SPDT (Single Pole Double Throw) allows one input to connect to one of two outputs.
Q4: What is the rated load?
It is typically AC125V 10A / AC250V 6A.
Q5: Does this rocker switch support OEM/ODM customization?
Yes, customization is available for LED indicator, symbols, wiring configuration, and specifications.
