Specifications
| Parameter | Details |
|---|---|
| Model | KCD1-104-N-4 |
| Switch Type | KCD Rocker Switch |
| Function | ON-OFF (Dual Circuit) |
| Pin | 4 Pin |
| Contact Type | DPST |
| Rated Load | AC125V 10A / AC250V 6A |
| Mounting Type | Snap-in Panel Mount |
| Indicator | LED (optional / N type) |
| Electrical Life | ≥10,000 cycles |
| Contact Resistance | ≤50mΩ |
| Insulation Resistance | ≥100MΩ |
Key Features
- 4 pin DPST dual circuit design
- Simultaneous ON-OFF switching for two circuits
- Optional LED indicator (N type commonly illuminated)
- Snap-in panel mount installation
- Durable thermoplastic housing
Applications
- Household appliances
- Industrial control panels
- Power distribution systems
- Electrical equipment
- DIY electronics
Widely used in electrical systems requiring synchronized dual circuit ON-OFF control with stable performance and clear power indication.
Why Choose Our Rocker Switch
- Professional KCD1-104-N-4 rocker switch supplier with stable production capacity
- OEM / ODM customization available for 4 pin DPST rocker switch manufacturer projects
- Reliable dual circuit ON OFF boat switch for power distribution and industrial systems
- High-quality panel mount rocker switch factory China with strict QC control
- Durable illuminated rocker switch for equipment status indication and control
- Fast delivery and global customer support
FAQ
Q1: What is a KCD1-104-N-4 rocker switch?
It is a 4 pin DPST ON-OFF rocker switch designed for dual circuit control in electrical systems.
Q2: What does a 4 pin DPST rocker switch do?
It allows simultaneous ON-OFF switching of two independent circuits using one switch.
Q3: What does the “N” mean in KCD1-104-N-4?
It usually indicates an illuminated version with an LED indicator.
Q4: What is the rated voltage and current?
Typically AC125V 10A and AC250V 6A
Q5: Does this switch support OEM/ODM customization?
Yes, customization is available for LED color, wiring configuration, branding, and application requirements.
