Specifications
| Parameter | Details |
|---|---|
| Model | KCD1-102-N-5 |
| Switch Type | KCD Rocker Switch |
| Function | ON-OFF |
| Pin | 3 Pin |
| Contact Type | SPST / extended wiring |
| Rated Load | AC125V 10A / AC250V 6A |
| Mounting Type | Panel Mount |
| Contact Resistance | ≤50mΩ |
| Insulation Resistance | ≥100MΩ |
| Electrical Life | ≥10,000 cycles |
Key Features
- 3 pin ON-OFF switching function
- Stable latching (self-lock) operation
- Supports indicator or extended wiring
- Snap-in panel mount installation
- Durable nylon housing with long lifespan
Applications
- Household appliances
- Power supplies
- Industrial control panels
- Electrical equipment
- Automation systems
Widely used in power control systems requiring reliable ON-OFF switching, stable electrical performance, and flexible wiring configurations.
Why Choose Our Rocker Switch
- Professional KCD1-102-N-5 rocker switch supplier with stable production capacity
- OEM / ODM customization available for 3 pin ON OFF rocker switch manufacturer projects
- Reliable boat rocker switch for appliances and industrial control systems
- High-quality panel mount rocker switch factory China with strict quality control
- Durable mini rocker switch for power control and automation applications
- Fast delivery and global customer support
FAQ
Q1: What is a KCD1-102-N-5 rocker switch?
It is a 3 pin ON-OFF rocker switch used for controlling power circuits in electrical and electronic systems.
Q2: What is the function of a 3 pin ON-OFF rocker switch?
It provides ON-OFF switching while allowing additional wiring options such as indicator light or circuit extension.
Q3: What is the difference between 2 pin and 3 pin rocker switch?
A 2 pin switch controls a basic circuit, while a 3 pin switch allows more flexible wiring and additional functions.
Q4: What is the rated voltage and current?
It is typically rated at AC125V 10A and AC250V 6A
Q5: Does this switch support OEM/ODM customization?
Yes, OEM/ODM services are available including color, marking, and functional customization.
