Specifications
| Parameter | Details |
|---|---|
| Model | KCD1-101-4 |
| Switch Type | KCD Rocker Switch |
| Function | Momentary (ON)-OFF |
| Pin | 2 Pin |
| Contact Type | SPST |
| Rated Load | AC125V 10A / AC250V 6A |
| Operating Mode | Spring return (reset) |
| Contact Resistance | ≤50mΩ |
| Insulation Resistance | ≥100MΩ |
| Electrical Life | ≥10,000 cycles |
Key Features
- Momentary (reset) rocker switch design
- Automatic return after release
- 2 pin simple control circuit
- Snap-in panel mount installation
- Durable structure with stable performance
Applications
- Control signal systems
- Industrial machinery start buttons
- Power tools
- Automation equipment
- Safety control circuits
Widely used in applications requiring temporary ON operation with automatic reset for safe and precise control.
Why Choose Our Rocker Switch
- Professional KCD1-101-4 momentary rocker switch supplier with stable production capacity
- OEM / ODM customization available for reset rocker switch manufacturer projects
- Reliable momentary boat switch for control signal and safety circuits
- High-quality panel mount rocker switch factory China with strict quality control
- Durable spring return rocker switch for industrial automation systems
- Fast delivery and global customer support
FAQ
Q1: What is a momentary rocker switch?
A momentary rocker switch only stays ON while being pressed and automatically returns to OFF when released.
Q2: What is the difference between momentary and latching rocker switch?
A latching switch stays ON or OFF after pressing, while a momentary switch resets automatically after release.
Q3: What is KCD1-101-4 used for?
It is used in control circuits, start buttons, and safety systems requiring temporary activation.
Q4: What is the rated voltage and current?
It is typically rated at AC125V 10A and AC250V 6A
Q5: Does this switch support OEM/ODM customization?
Yes, OEM/ODM services are available including color, marking, and specification customization.
