Specifications
| Parameter | Details |
|---|---|
| Model | KCD1-101-2 |
| Switch Type | KCD Rocker Switch |
| Function | ON-OFF |
| Contact Type | SPST |
| Pin | 3 Pin |
| Rated Load | AC125V 10A / AC250V 6A |
| Environmental Temperature | -25℃ to +70℃ |
| Relative Humidity | ≤95% at 40℃ |
| Withstand Voltage | AC 500V 50Hz / 1min |
| Contact Resistance | ≤0.05Ω |
| Insulation Resistance | >100MΩ |
| Electrical Life | 10,000 cycles min |
Key Features
- 3 pin ON-OFF switching function
- Flexible circuit control design
- Snap-in panel mount installation
- Compact boatlike structure
- Stable electrical conductivity
Applications
- Household appliances
- Power supplies
- Audio equipment
- Industrial control panels
- DIY electronics
Widely used in electrical systems requiring flexible ON-OFF switching and reliable power control with simple installation.
Why Choose Our Rocker Switch
- Professional KCD1-101-2 rocker switch supplier with stable production capacity
- OEM / ODM customization available for 3 pin rocker switch manufacturer projects
- Reliable ON OFF boat switch for appliances and industrial equipment
- High-quality panel mount rocker switch factory China with strict quality control
- Durable mini rocker switch for power control systems and DIY electronics
- Fast delivery and global customer support
FAQ
Q1: What is a KCD1-101-2 rocker switch?
It is a 3 pin ON-OFF rocker switch used to control electrical circuits in appliances and electronic equipment.
Q2: What is the difference between 2 pin and 3 pin rocker switch?
A 2 pin switch controls a simple ON-OFF circuit, while a 3 pin switch can provide additional circuit flexibility such as indicator light or alternate wiring.
Q3: What is the rated voltage and current?
It is typically rated at AC125V 10A and AC250V 6A.
Q4: Where can this rocker switch be used?
It is widely used in household appliances, power supplies, industrial control panels, and electronic systems.
Q5: Does this rocker switch support OEM/ODM customization?
Yes, OEM/ODM services are available including color, marking, and specification customization.
