Specification Table:
| PRODUCT NAME | XLR 1/4 COMBO JACK CONNECTOR |
| MODEL | CTCK-12WP-11 |
| TYPE | XLR Combo Jack |
| RATED LOAD | 50V AC 7.5A |
| CONTACT RESISTANCE | XLR<10mQ, JACK<20mQ |
| WITHSTAND VOLTAGE | 1600V, AC/min |
| TEMPERATURE | -20℃~+65°℃ |
| LIFE | 5000 time |
| STRENGTH | 10N ~55N |
| COLOR | Black |
XLR Combo Jack vs Standard XLR Connector
| Type | Function | Application |
|---|---|---|
| Standard XLR | Microphone / balanced signal | Basic audio input |
| XLR Combo Jack | XLR + 1/4" shared input | Mixers / amplifiers / stage audio |
Key Features
- XLR + 1/4" combo input design
- Space-saving panel mount structure
- Supports mic and line signal input
- Durable housing and stable performance
- Ideal for professional audio systems
Applications
- Audio mixers
- Power amplifiers
- Stage boxes
- PA systems
- Professional audio equipment
Widely used in audio devices requiring flexible XLR and 1/4 inch combined input connections for microphones, instruments, and line-level signals.
Why Choose Our Combo Jack Connector
- Professional connector manufacturer
- OEM / ODM customization
- Strict quality control
- Fast delivery
- Competitive factory pricing
- XLR 1/4 combo jack connector supplier
- combo jack connector manufacturer China
- panel mount XLR 6.35mm combo socket factory
- XLR combo connector for mixer input
- buy combo jack connector in bulk
FAQ
Q1: What is an XLR 1/4 combo jack connector?
It is a dual-function audio connector that combines an XLR input and a 1/4 inch jack into one socket for flexible audio connections.
Q2: What is the advantage of a combo jack connector?
It saves panel space and allows one connector to accept both XLR and 6.35mm plugs, improving design efficiency.
Q3: Can this connector be used in mixers and amplifiers?
Yes, it is widely used in mixers, amplifiers, stage boxes, and PA systems.
Q4: What signals can this connector support?
It supports microphone signals (XLR) and line or instrument signals (1/4 inch jack).
