Specification Table:
| PRODUCT NAME | XLR 1/4 COMBO JACK CONNECTOR |
| MODEL | CTCK-12H-10 |
| TYPE | XLR Combo Jack |
| RATED LOAD | 50V AC 7.5A |
| CONTACT RESISTANCE | XLR<10mQ, JACK<20mQ |
| WITHSTAND VOLTAGE | 1600V, AC/min |
| TEMPERATURE | -20℃~+65℃ |
| LIFE | 5000 time |
| STRENGTH | 10N ~55N |
| COLOR | Black |
XLR Combo Jack vs Standard XLR Connector
| Type | Function | Application |
|---|---|---|
| Standard XLR | Microphone / balanced signal | Basic audio input |
| XLR Combo Jack | XLR + 1/4" shared input | Mixers / amplifiers / stage audio |
Key Features
- XLR and 1/4" combo input design
- Space-saving connector structure
- Horizontal PCB mount design
- Stable low-noise signal transmission
- Suitable for professional audio equipment
These points align with the product page’s stated hybrid 2-in-1 design, horizontal PCB mount, space-saving structure, and low-noise signal positioning.
Applications
- Audio mixers
- Active speakers
- Audio interfaces
- Stage audio equipment
- PA systems
Widely used in audio devices requiring compact combined XLR and 1/4 inch input connections for microphone, line, and instrument signals. Combo connectors are commonly used for line/mic inputs, active loudspeaker systems, mixers, effect devices, and portable gear where space-saving panel design matters.
Why Choose Our Combo Jack Connector
- Professional connector manufacturer
- OEM / ODM customization
- Stable quality control
- Fast delivery support
- Competitive factory pricing
- XLR 1/4 combo jack connector supplier
- combo jack connector manufacturer China
- panel mount XLR 6.35mm combo socket factory
- XLR female 1/4 combo connector for mixer
- buy combo jack connector in bulk
FAQ
Q1: What is an XLR 1/4 combo jack connector?
It is a combined audio socket that integrates an XLR receptacle and a 1/4 inch jack into one connector for compact panel input design. Neutrik’s combo FAQ and product pages describe it as a combined XLR chassis connector and 1/4" phone jack in one housing.
Q2: What is the advantage of a combo jack connector?
It saves panel space and allows one connector position to accept different input formats, which is useful in compact professional audio devices. The product page and industry references both emphasize the space-saving benefit.
Q3: Can this connector be used in mixers and active speakers?
Yes. The product page explicitly positions this model for mixers, active speakers, and audio interfaces, and industry references also list mixers and active loudspeaker systems as typical combo-jack applications.
Q4: What is the difference between a combo jack and a standard XLR socket?
A combo jack accepts both XLR and 1/4 inch plugs, while a standard XLR socket only accepts XLR connectors.
