Specification Table:
| PRODUCT NAME | XLR 1/4 COMBO JACK CONNECTOR |
| MODEL | CTCK-12GP-07 |
| TYPE | XLR Combo Jack |
| RATED LOAD | 50V AC 7.5A |
| CONTACT RESISTANCE | XLR<10mQ, JACK<20mQ |
| WITHSTAND VOLTAGE | 1600V, AC/min |
| TEMPERATURE | -20℃~+65℃ |
| LIFE | 5000 time |
| STRENGTH | 10N ~55N |
| COLOR | Black |
XLR Combo Jack vs Standard XLR Connector
| Type | Function | Application |
|---|---|---|
| Standard XLR | Microphone / balanced signal | Basic audio input |
| XLR Combo Jack | XLR + 1/4" shared input | Mixers / amplifiers / stage audio |
Key Features
- XLR and 1/4" combo input design
- Panel / PCB mount structure
- Space-saving dual-function connector
- Supports mic, line, and instrument signals
- Stable and low-noise signal transmission
Applications
- Audio mixers
- Active speakers
- Audio interfaces
- Stage equipment
- PA systems
Widely used in audio devices requiring combined XLR and 1/4 inch inputs for microphone, line-level, and instrument signal connections in compact panel designs.
Why Choose Our Combo Jack Connector
- Professional connector manufacturer
- OEM / ODM customization
- Stable quality control
- Fast delivery
- Competitive factory pricing
- XLR 1/4 combo jack connector supplier
- combo jack connector manufacturer China
- panel mount XLR 6.35mm combo socket factory
- XLR combo connector for mixer input
- buy combo jack connector in bulk
FAQ
Q1: What is an XLR 1/4 combo jack connector?
It is a hybrid audio connector that integrates an XLR socket and a 1/4 inch jack into one unit for flexible signal input.
Q2: What is the advantage of a combo jack connector?
It saves panel space and allows one connector to support multiple input types, making it ideal for compact audio devices.
Q3: Can this connector be used in mixers and active speakers?
Yes, it is widely used in mixers, active speakers, audio interfaces, and stage equipment.
Q4: What signals does this connector support?
It supports microphone signals via XLR and line or instrument signals via the 1/4 inch jack.
