Specification Table:
| MODEL | CTCK-11H |
| TYPE | XLR Combo Jack |
| RATED LOAD | 50V AC 7.5A |
| CONTACT RESISTANCE | XLR<10mQ, JACK<20mQ |
| WITHSTAND VOLTAGE | 1600V, AC/min |
| TEMPERATURE | -20℃~+65℃ |
| LIFE | 5000 time |
| STRENGTH | 10N ~55N |
| COLOR | Black |
XLR Combo Jack vs Standard XLR Connector
| Type | Function | Application |
|---|---|---|
| Standard XLR | Microphone / balanced signal | Basic audio input |
| XLR Combo Jack | XLR + 1/4" shared input | Mixers / amplifiers / stage audio |
Key Features
- XLR and 1/4" combo input design
- Panel mount structure for secure installation
- Space-saving dual-function connector
- Stable and low-noise signal transmission
- Suitable for professional audio equipment
Applications
- Audio mixers
- Amplifiers
- Audio interfaces
- Stage equipment
- PA systems
Widely used in audio devices requiring combined XLR and 1/4 inch inputs for microphones, line-level, and instrument signal connections in compact panel designs.
Why Choose Our Combo Jack Connector
- Professional connector manufacturer
- OEM / ODM customization
- Stable quality control
- Fast delivery
- Competitive factory pricing
- XLR combo jack connector supplier
- panel mount combo connector manufacturer China
- XLR 6.35mm combo socket factory
- combo jack connector for mixer input
- buy XLR combo connector in bulk
FAQ
Q1: What is an XLR 1/4 combo jack connector?
It is a combined audio socket that integrates an XLR connector and a 1/4 inch jack into one interface for flexible signal input.
Q2: What is the advantage of a combo jack connector?
It saves panel space and allows multiple signal types in one connector, making it ideal for compact audio equipment.
Q3: Can this connector be used in mixers and amplifiers?
Yes, it is widely used in mixers, amplifiers, audio interfaces, and stage equipment.
Q4: What is the difference between combo jack and standard XLR?
A combo jack supports both XLR and 1/4 inch plugs, while a standard XLR connector only supports XLR plugs.
