Specification Table:
| PRODUCT NAME | XLR PANEL MOUNT CONNECTORS |
| MODEL | CT7-15 |
| PIN | 7 PIN |
| RATED LOAD | 250V DC 1.0A |
| CONTACT RESISTANCE | ≤ 0.020 |
| WITHSTAND VOLTAGE | 1500V, AC/min |
| TEMPERATURE | -30℃~+80℃ |
| LIFE | 5000 time |
| TERMINAL STRENGTH | ≥ 30N |
| CUSTOMIZED | OEM / ODM |
3 Pin vs 5 Pin vs 7 Pin XLR Panel Connector
| Type | Signal | Application |
|---|---|---|
| 3 Pin | Balanced audio | Microphones |
| 5 Pin | DMX / control | Lighting |
| 7 Pin | Multi-signal | Tube mic / broadcast |
Applications
- Broadcast equipment
- Tube microphones
- Studio audio systems
- Industrial control panels
- Rack-mounted audio devices
Widely used in professional systems requiring multi-signal transmission and standardized panel installation.
Why Choose Our XLR Connector
- Professional connector manufacturer
- OEM / ODM customization
- Standard D-size compatibility
- Stable multi-signal transmission
- Competitive factory pricing
- 7 pin XLR panel mount connector supplier
- D size XLR chassis socket manufacturer
- 7 pin XLR connector for tube microphone
- professional panel mount audio connector
- buy 7 pin XLR connector in bulk
FAQ
Q1: What is a 7 pin XLR panel mount connector?
It is a chassis-mounted connector used for transmitting multiple signals such as audio, power, and control in one interface.
Q2: What is the advantage of D-size XLR connectors?
D-size connectors follow a standardized panel cutout, ensuring compatibility across most professional equipment.
Q3: What is a 7 pin XLR used for?
It is commonly used in tube microphones, broadcast systems, and industrial control applications.
Q4: What is the difference between CT7-15 and cable connectors?
CT7-15 is a panel-mounted socket for equipment, while cable connectors are used on cables.
Q5: Is this compatible with Neutrik-style connectors?
Yes, it follows standard XLR dimensions and is compatible with most industry-standard plugs.
