Specification Table:
| Product Name | PowerCon Connector 3 Pin Male and Female Head Connector |
| Model | HPA-04BL |
| Pin | 3 PIN |
| Contact Resistance | <0.01 ΜΩ |
| Insulation Resistance | ≥2 GQ |
| Withstand Voltage | 2.7 KV |
| Terminal Strength | ≥30 N |
| Rated Load | 250V AC |
| Temperature | -25 ~+70℃ |
| Life | 5000 Time |
Key Features
- 3-pin PowerCON AC connector (L / N / PE)
- 20A / 250V high current capacity
- Secure locking system (twist lock)
- Panel mount chassis socket
- Durable insulated housing
Applications
- Stage lighting systems
- LED display power distribution
- Audio & video equipment
- Power distribution units (PDU)
- Industrial electrical equipment
HPA-04BL vs HPB-04BL vs HPA-05GY
| Model | Type | Advantage |
|---|---|---|
| HPA-04BL | PowerCON female (panel) | Secure locking & high current capacity |
| HPB-04BL | Cable connector | Flexible cable connection |
| HPA-05GY | Power-out type | Power output distribution |
Why Choose Our PowerCON Connector?
- Professional connector manufacturer
- OEM / ODM customization
- High current (20A) power solution
- Secure locking connection design
- Reliable performance for stage & industrial use
- powercon panel mount connector supplier
- 3 pin powercon female connector manufacturer China
- stage lighting power connector 20A
- locking AC power connector panel mount
- buy powercon connector in bulk
FAQ
Q1: What is a PowerCON connector?
It is a locking AC power connector used in professional audio, lighting, and industrial equipment.
Q2: What is the difference between PowerCON and XLR?
PowerCON is used for power transmission, while XLR is used for audio signals.
Q3: What does 3 pin PowerCON mean?
It includes Line (L), Neutral (N), and Protective Earth (PE).
Q4: What is the advantage of locking connectors?
They prevent accidental disconnection during operation.
Q5: Where is this connector commonly used?
It is widely used in stage lighting, LED displays, and AV systems.
